Conductivity Indicators Controllers

Our firm is occupied in providing a huge range of Conductivity Indicators Controllers. These are used to measure either solution conductivity. These controllers are one of the most common environmental tests of aquatic samples. Apart from these series, easily procured in various configurations to meet the current needs of consumers. Conductivity Indicators Controllers are an automated device to control external devices. These are convenient to place at a fixed distance under the assistance of talented professionals. These are suitable in chemicals, pharma, water and other industries.

Get a Price/Quote

2 Set-Point Digital Conductivity Controller

Request To Call Back

Product Details:

We are providing a unique arrangement of 2 Set-Point Digital Conductivity Controller. It is designed for fast and accurate measurement. This controller is able to allows us to measure the level of conductivity in solutions. 2 Set-Point Digital Conductivity Controller helps to pass an electric current. Furthermore, provided controller is an external devices based on the measured conductivity value. It is an automated device which ensures an internal alarm set discourages unauthorized adjustments

Specification

Display	3 Digit LCD
Range	a. 199.9s b. 1999s c. 19.99ms d. 199.9ms The range is selectable from the rear and can be calibrated by Cell Adj at the front for individual range.
Resolution	0.1s to 0.1ms depending on range selected.
Accuracy	0.5% of Full Scale 1 Least Significant Digit.
Sensor	Contact Type with Cell Constant 1.0
Temperature	Uses PT100, precision temperature sensor (External).
Compensation	The Compensation is internally set at 2% per C NOTE: If PT100 is not available, then fix a simulated resistance of PT100 @ 25C approx. 110. Instrument will not work otherwise.
Limit Setting	Using 2 Nos. 10 turn precision trimpots on front panel to set the High/Low Limi
Control Output	Two set of NO-P-NC, 5 Amps potential free Relay Contacts. a. Relay 1 (High) ON, for Conductivity > High Limit b. Relay 2 (Low) ON, for Conductivity < Low Limit
Recorder Output	0-2V for the selected range Max. current output capability 2mA
Supply	110V AC/220V AC 15% Internally selectable
Size	Front Fascia 96mm x 96mm, Cut Out 92mm x 92mm
Cabinet	Flame retardant grade Plastic enclosure

Digital Conductivity cum TDS Indicator

Product Details:

Model code:5500
Product Name:Digital Conductivity cum TDS Indicator
Category:conductivity_meters_controllers
Sub Category:conductivity_indicators

Specification

Display	3 Digit 13mm High, RED LED.
Cell Factor	1.0 & 0.1 Selectable.
Conductivity Range	A)For Cell Factor 1.0 1) 199.9 mS/cm 2) 19.99 mS/cm 3) 19999 mS/cm 4) 199.9 mS/cm : B)For Cell Factor 0.1 1) 19.99 mS/cm 2) 19999 mS/cm 3) 199.9 mS/cm 4) 19.99 mS/cm
TDS Range	2000 ppm
Temperature Compensation	Automatic Using External PT-100 Sensor..
Display	3 Digit 13mm High, RED LED.
Cell Factor	1.0 & 0.1 Selectable.
Conductivity Range	A)For Cell Factor 1.0 1) 199.9 mS/cm 2) 19.99 mS/cm 3) 19999 mS/cm 4) 199.9 mS/cm : B)For Cell Factor 0.1 1) 19.99 mS/cm 2) 19999 mS/cm 3) 199.9 mS/cm 4) 19.99 mS/cm
TDS Range	2000 ppm
Temperature Compensation	Automatic Using External PT-100 Sensor..

Conductivity TDS pH ORP Indicator

Product Details:

Backed by a cutting edge technology, we have become a promising manufacturer and trader of a wide gamut of Conductivity TDS pH ORP Indicator. Our offered indicator is precisely fabricated by our experienced experts by making use of technologically advanced machines and equipments at our production unit. Also, it is in compliance with all the set quality guidelines of the industry. Our range of Conductivity TDS pH ORP Indicator is best known for features like accurate dimensions, strong structure, corrosion resistance, and so on.

Model code:5501
Product Name: Conductivity TDS pH ORP Indicator
Category: conductivity_ meters_ controllers
Sub Category: conductivity_ indicators

Features

Accurate pH display with 0.01pH resolution
Auto buffer recognition with 2 point calibration for pH
Auto/Manual temperature compensation selectable for both pH and Conductivity
4 Step Range selection 0.1s to 199.9ms for conductivity
Cell Factor selectable for both 1.0 and 0.1
Digital calibration for conductivity
Auto Temp Compensation using PT100 sensor
One touch switching between conductivity and pH display selections
Large alphanumeric LCD display with bright back light
Aesthetically designed front panel with membrane switches and sleek bench top cabinet

Specification

Display	2 line large alphanumeric display with back light illumination
Ranges	pH: 0.00 to 14.00 pH ORP: 0-2000mV Conductivity: 19.99ms/1999s/199.9s/19.99s in 0.1 Cell Constant 199.9ms/19.99ms/1999s/199.9s in 1.0 Cell Constant TDS: 0-1999ppm
Resolution	pH: 0.01pH ORP: 1mV Conductivity: 0.01ms or 0.01s depending on range & Cell factor TDS: 1ppm
Auto Temp. Comp.	0-100C using PT100 external sensor for pH and Conductivity
Manual Temp. Comp.	Settable from front panel from 0-100.0C for pH and Conductivity
pH Calibration	2 Point calibration with auto buffer recognition. Buffers recognized: 4.00, 7.00, 9.00, 10.00 pH
Conductivity Calibration	Digital calibration by factor multiplication from 0.75-1.25
Accuracy	0.5% 1 Digit
Supply	220V AC 10% @ 50Hz
Enclosure	Plastic (ABS). Size 272x192x90mm
Weight	900gms

Conductivity Transmitter

Product Details:

We are a leading manufacturer and trader of a wide gamut of Conductivity Transmitter. Used for various industrial applications, our range of transmitter is manufactured by making use of high grade basic materials which are sourced from reliable vendors of the industry. Our range of Conductivity Transmitter is best known for its aesthetically designed weather-proof cabin. Also, we have made it available for clients in different range starting from 19.99 s to 199.9mS (Factory Set). Also, these are timely delivered to clients end in a timely manner.

Model code:1004
Product Name: Conductivity Transmitter
Category: conductivity _meters _controllers
Sub Category: conductivity_ indicators

Features

Precision indication of conductivity in 4-20mA output
Automatic Temperature Compensation @2%/C using PT-100
Range can be provided from 19.99 s to 199.9mS (Factory Set)
Aesthetically designed weather-proof cabin

Specification

Range	19.99ms 199.9ms
(Factory Set)	1999 s 19.99ms 199.9s 1999 s 19.99s 199.9s (0.1Cell) (1.0 Cell)
Accuracy	0.5% of F.S. 1 LSD
Sensor	Contact type with Cell constant 0.1 or 1.0.
Temp.	Uses PT-100, precision temperature Comp. sensor (external). The compensation is internally set at 2%/C
Supply	220V AC 15% @ 50Hz/60Hz
Size	198mm x 89mm x 60mm (LxWxH) with flange
